Before I start I want to say that I'm rather new to editing ped stuff and this is extremely confusing and I'm probably going to explain it badly but I really wanna figure this stuff out so if anyone can help out it would be massively appreciated, and if anything is unclear I can elaborate further.
I use EUP and wish to add a new vest to use in the 'Armor' slot in the EUP menu which is a 'task' component. I have the vest as task_000 (task_000_u.ydd, task_diff_000_a_uni.ytd and task_diff_000_b_uni.ytd). I went into the normal game dlcpacks and found that mpvinewood has many task components, so I went to the EUP dlcpack folder and added a folder named "mp_m_freemode_01_mp_m_vinewood" in eup_componentpeds.rpf. If I place the vest files into this folder they load and work fine as drawable 39 in the 'Armor' slot, however the second texture (task_diff_000_b_uni.ytd) doesn't load.
I went into the normal mpvinewood dlcpack and attempted to edit the the "mp_m_freemode_01_mp_m_vinewood.ymt" file. I used MetaToolkit to convert this into an .xml.
<hash_B29BE228>255 0 1 2 3 255 4 5 6 7 8 9</hash_B29BE228>
As I understand, 255 means the component isn't used but I have come across some conflicting lists as to what these numbers mean. I tried to figure it out myself by going through each <Item> entry under <hash_E2489C4F> and finding whatever one has the same amount of entries as the amount of 'task' files in the dlcpack, which turned out to be the 8th <Item> entry but when I edited the first component entry from:
<Item>
<hash_AECFE243 value="5" />
<hash_A7431FBA value="0" />
<hash_4A92222A>
<Item>
<texId value="0" />
<hash_36896D17 value="255" />
</Item>
</hash_4A92222A>
<hash_92E68DB3>
<hash_A893A361 value="false" />
</hash_92E68DB3>
</Item>
To:
<Item>
<hash_AECFE243 value="5" />
<hash_A7431FBA value="0" />
<hash_4A92222A>
<Item>
<texId value="0" />
<hash_36896D17 value="255" />
</Item>
<Item>
<texId value="0" />
<hash_36896D17 value="255" />
</Item>
</hash_4A92222A>
<hash_92E68DB3>
<hash_A893A361 value="false" />
</hash_92E68DB3>
</Item>
The second texture was still not selectable in-game, even though to my understanding this should have added a new texture variant to that component (task_000).
I went into the EUP folder and navigated to "mp_m_freemode_01_mp_m_vinewood" and placed the vest files in there replacing task_000. The vest loaded, but I could not change the texture. I tried putting the vest files into the actual mpvinewood dlcpack folder (first removing it from the EUP one) and again, the vest loaded, but I could not select the second texture.
I understand this is rather long and I may have made it somewhat confusing but I tried to the best of my ability to wrap my head around this. Thank you to anyone that took the time to read this.
